| Performance Output | 12 Volts 170 Amps (100 Amps at idle) 24 Volts 105 Amps |
| Maximum Speed | 8,000 RPM Continuous 10,000 RPM Intermittent |
| Rotation | Clockwise Counterclockwise |
| Temperature Rating | 125°C / 257°F |
| Mounting | J180 Short Hinge Quad Pad |
| Polarity | Negative Ground (Standard) Isolated Ground (Available) |
| Efficiency | 68% |
| Weight | 25.4 lbs / 11.5 kg |
| Stator Diameter | 5.98 in / 152 mm |
| Length | 10.35 in / 263 mm |
| Remote Sense | Optional |
| Warranty *(US /Canada Only) |
3 year / 350,000 miles – New Service 2 year / 250,000 miles – Reman |
36SI™ Brushless Type Alternator
